What are the key points of quality control for PCBA wave soldering in SMT patch factories?
1. Application of parallel management mechanism in product development • Importance: In production practice, soldering defects caused by poor PCBA design are endless. For such defects, it is difficult to work by improving operations and innovating processes alone. Therefore, it is necessary to adopt a parallel management mechanism in the product development stage. • Implementation method: The quality control of wave soldering should start from the design stage of PCBA, and let the idea of this stage run through the entire process before delivery and packaging. At the beginning of each new PCBA design, a mechanism of mutual trust and cooperation between design, process, production and quality inspection personnel should be established. In other words, it is necessary to implement a parallel technical route for process, production and quality inspection personnel to intervene in product development at an early stage. This is the correct way to solve soldering defects caused by poor design.
2. Establishment of component solderability management mechanism • Importance: The solderability of the metal surface depends on the degree of removal of surface dirt and oxide film and the inherent wettability of the metal. Maintaining good solderability of component leads is the basis for obtaining excellent solder joints and an important measure to improve production efficiency. • Implementation method: When purchasing components, PCBs, terminals, etc., it is necessary to add provisions such as solderability and the time to maintain the wet temperature limit to the delivery technical conditions of the components. This can ensure that the solderability of the components is appropriate, thereby reducing the quality risk in the welding process.
III. Strict control of production process • SMT accuracy and stability: During the SMT patch process, the accuracy and stability of the patch machine need to be accurately controlled to ensure that the components can be accurately embedded in the specified position. • Welding parameter optimization: During wave soldering, it is necessary to optimize the welding parameters, such as welding temperature, welding time, etc., to ensure welding quality. At the same time, it is also necessary to monitor the welding process in real time to promptly discover and deal with potential quality problems.
IV. Environmental control • Maintain a constant temperature, humidity, and dust-free environment: During the PCBA processing process, it is necessary to maintain a constant temperature, humidity, and dust-free environment in the production workshop to resist interference from static electricity, dust, etc. on welding quality. • Regular calibration of production equipment: Regularly calibrate and maintain production equipment to ensure its accuracy and stability, and provide solid guarantee for the excellent quality of products.
V. Inspection and testing • Appearance inspection and electrical performance test: Carry out an appearance inspection of PCBA to check whether there are welding defects, component misalignment and other problems. At the same time, conduct electrical performance tests to ensure that the electrical performance of the circuit board meets the design requirements. • Application of high-tech detection methods: Use high-tech methods such as AOI (automatic optical inspection) and X-Ray inspection to timely discover and deal with potential quality risks.
VI. Personnel training and management • Professional skills training: Production personnel need to receive professional skills training and quality awareness to ensure that they are proficient in production processes and quality control standards. • Quality responsibility system construction: Build a complete quality responsibility system, clarify the responsibilities and assessment standards of each position, and improve the quality awareness and sense of responsibility of all employees. In summary, the key points of SMT patch factory patch proofing PCBA wave soldering quality control involve parallel management mechanism, component solderability management mechanism, production process control, environmental control, inspection and testing, and personnel training and management. Only by fully controlling these key points can we ensure the stable and reliable quality of PCBA wave soldering.
